Details
- Sold individually
- 5/8″ radius corner
- Supplied standard with 6-10X1″ Flat Head-Phillips wood screws. Wood screws are fully threaded to the head and have an undercut head for secure installations. It is recommended to install screws by hand, not power tools.
- Extruded brass, full mortise hinges are machined for precise installation and smooth movement
- Knuckles are milled to a clearance of 0.010″ (.25″mm) to minimize vertical wear
- Each hinge is beveled on the inside leaf to obtain a tight fit when viewing the hinge in a closed position
- Furnished with stainless steel, rust proof pins for added durability.
- Application: Baldwin full mortise hinges are classified as STANDARD WEIGHT for installation on doors up to 1.75″ in thickness
- Number of Hinges: Use three hinges on doors up to and including 7.5ft and one additional hinge for each additional 2.5ft or fraction thereof.
- Hinge thickness: .090″
- NON-REMOVABLE PINS not available on radius corner hinges
- Questions? please call 1-800-358-2469 to speak with a Baldwin specialist or to order by phone
