- 15 Amp, 5,000 rpm motor delivers extended power and durability
- Stainless steel detent plate with 11 positive stops provides repeatable accuracy and jobsite duability
- Tall sliding fences support crown molding vertically 4-1/2″ and easily slides out of the way for bevel cuts
- Machined base fence support maintains fence perpendicularity with blade for cutting accuracy
- Cam miter lock for quick and accurate miter table positioning
- Miter detent override for fine adjustment and precise miter angles
- 0-50° left and right miter capacity for greater versatility
- Bevels 3°-48° for increased cut capacity
- Lightweight (35lbs), built-in carrying handle for increased portability
Specifications
| Blade Diameter | 10″ |
|---|---|
| Amps | 15Amps |
| No Load Speed | 5,000rpm |
| Arbor Size | 5/8″ |
| Vertical Capacity: Baseboard Against Fence | 3-1/2″ |
| Vertical Capacity: Crown Molding Vertically Nested | 4-1/2″ |
| Horizontal Capacity: Baseboard Lying Flat | 6″ |
| Horizontal Capacity: Crown Molding Lying Flat | 5-1/4″ |
| 45° Bevel Cut Capacity (dimensional lumber) | 2×6 |
| 90° Cross-Cut Capacity (dimensional lumber) | 4×4″ |
| 90° Cross-Cut Capacity (Max Width) | 2×6 dimensional lumber |
| 45° Miter Cut Capacity (Max Height) | 2×4 |
| 45° Miter Cut Capacity (Max Width) | 2×4 |
| Tool Weight | 35lbs |
| Shipping Weight | 38lbs |
Includes:
- Blade Wrench
- Carbide Blade
- Users Guide
