- 15 Amp motor, 4,000 rpm delivers extended power and durability
- Adjustable stainless steel miter detent plate with 11 positive stops improves productivity and ensures cutting
- Precise miter system and machined base fence support optimize cutting accuracy
- Tall sliding fence supports crown molding up to 5-1/4″ nested and base molding up to 6-1/2″ vertically against the fence while easily sliding out of the way for bevel cuts
- Bevels 0°-48° to the left and 0°-3° to the right for increased capacity
- 0°-50° left and right miter capacity for greater versatility
- Lightweight (42 lbs.) with built-in carry handle for easy portability
- Cam lock miter handle with detent override deliver quick and accurate miter angles
- 3 Hardened Steel Bevel Stops at 0°, 33.9°, and 45° delivers versatility at most common bevel angles
Specifications
| Blade Diameter | 12″ |
|---|---|
| Amps | 15Amps |
| No Load Speed | 4,000rpm |
| Arbor Size | 5/8″ or 1″ |
| Vertical Capacity: Baseboard Against Fence | 6-1/2″ |
| Vertical Capacity: Crown Molding Vertically Nested | 5-1/4″ |
| Horizontal Capacity: Baseboard Lying Flat | 8″ |
| Horizontal Capacity: Crown Molding Lying Flat | 6-1/2″ |
| 45° Bevel Cut Capacity (dimensional lumber) | 2×8 |
| 90° Cross-Cut Capacity (dimensional lumber) | 4×6″ |
| 90° Cross-Cut Capacity (Max Width) | 2×8 |
| 45° Miter Cut Capacity (Max Height) | 4×4 dimensional lumber |
| 45° Miter Cut Capacity (Max Width) | 2×6 dimensional lumber |
| Tool Weight | 42lbs |
| Shipping Weight | 49lbs |
Includes:
- Carbide blade
- Dust bag
- Blade wrench
