- 15.0 Amp, 3,800 rpm motor delivers extended power and durability
- Adjustable stainless steel miter detent plate with 11 positive stops Improves productivity and ensures cutting accuracy
- Precise miter system and machined base fence support optimize cutting accuracy
- Tall sliding fences support crown molding up to 6-5/8″ nested and base molding up to 6-1/2″ vertically against the fence while easily sliding out of the way for bevel cuts
- Innovative gearbox and belt-drive design increases vertical cutting capacity
- Double bevel design allows saw to bevel left and right 0° – 48° with positive stops at 0°, 33.9°, 45° and 48° both left and right allowing user to flip the saw not the material
- Exclusive Back Fence Design Cuts dimensional lumber 2 ” x 10″ at 90° and 2″ x 8″ at 45°
- 0-50° left and right miter capacity for greater versatility
- Lightweight (44 lbs.), head lock-down pin, and built-in carrying handle for increased portability
- Cam lock miter handle with detent override deliver quick and accurate miter angles
Specifications
| Blade Diameter | 12″ |
|---|---|
| Amps | 15Amps |
| No Load Speed | 3,800rpm |
| Arbor Size | 5/8″ or 1″ |
| Vertical Capacity: Baseboard Against Fence | 6-1/2″ |
| Vertical Capacity: Crown Molding Vertically Nested | 6-5/8″ |
| Horizontal Capacity: Baseboard Lying Flat | 10″ |
| Horizontal Capacity: Crown Molding Lying Flat | 6-1/2″ |
| 45° Bevel Cut Capacity (dimensional lumber) | 2×8 (2×10 with back fence) left and right |
| 90° Cross-Cut Capacity (dimensional lumber) | 2×8 (2×10 with back fence)” |
| 90° Cross-Cut Capacity (Max Width) | 2×8 (2×10 with back fence) |
| 45° Miter Cut Capacity (Max Height) | 4×6 dimensional lumber |
| 45° Miter Cut Capacity (Max Width) | 2×6 (2×8 with back fence) dimensional lumber |
| Tool Weight | 44lbs |
| Shipping Weight | 49lbs |
Includes:
- Carbide blade
- Dust bag
- Blade wrench
