- Internal inertial brakes plus the external energy absorber deliver max weight capacity and max below D-ring anchorage distance
- Kevlar web lifeline protects against Arc Flash hazards.
- Overmolded glass-filled nylon housing contributes unmatched impact resistance
- The energy absorber features a Nomex ViewPack cover with an inspection window and WrapPack label protection
- Integrated aluminum alloy swivel-eye helps to prevent lifeline twisting for smooth operation
- Features alloy-steel snap hook anchorage connector
- Includes aluminum alloy dorsal connecting carabiner
- May be anchored up to 5′ below the dorsal D-ring for users weighing up to 425 lb max. with OSHA-only compliance
- Complies with ANSI Z359.14-2014 and ASTM F887-13
-
Webbing
Kevlar; 4,500 lb min.
Energy Absorber
Polyester tear-away
Anchorage Connector
Aluminum alloy; 5,000 lb min. static strength with 3,600 lb gate strength
Dorsal Connector
Plated alloy steel; 5,000 lb min. static strength with 3,600 lb gate strength
-
Static Strength
3,600 lb min.
ANSI SRL Class/Type
Class 1 SRL-P
Avg. Arrest Force
900 lb
Max. Arrest Force
1,800 lb
Max. Arrest Distance
42″
ANSI User Capacity
130 to 310 lb max.
OSHA User Capacity
130 to 425 lb max.
SKU: 82909SC1
