Description:
- Powerful 1 HP motor
- Line interruption electro-mechanical switch needs a restart after a power failure
- Spindle is supported by high quality ball bearings
- Cast-iron pulleys reduce vibrations
- 45° tilting table for angular drilling
- Non-slip rubber feed handles
- 16 speeds
- Light socket incorporated into drill press head (standard light bulb not included)
Specifications:
- CAPACITY: 3/4″
- CHUCK SIZE: 5/8″
- SWING: 17″
- STROKE: 3-1/4″
- MAX. DISTANCE FROM CHUCK TO TABLE: 23-3/4″
- MAX. DISTANCE FROM CHUCK TO BASE: 44″
- TABLE SIZE: 13-3/4″
- SPINDLE TAPER: MT 2
- QUILL DIAMETER: 65 mm
- SPEEDS: 16 (240-3,400) RPM
