Description:
- Powerful 3 HP motor
- Parallelogram table adjustment system
- 3 knife cutterhead allows rapid cutting while producing a superior finish
- Precision ground cast-iron tables
- Lever actuated infeed table, with lock handle, for quick and easy height adjustments
- Imperial/Metric depth-of-cut scale
- Easy access push-button on/off switch is conveniently positioned behind and above the table
- Connect a dust collection system to its 5” dust hood
- Knives rest on adjustable Jack Screws; lock bar and lock screws keep knives in place
- Sliding bar T-handle controls fence angle adjustment and locks with a single control
- Includes 2 safety push blocks
Specifications:
- CAPACITY: 12″
- CUTTERHEAD SPEED: 5,000 RPM
- DIAMETER OF THE CUTTERHEAD: 3-7/8″
- RABBETING CAPACITY: 3/4″ x 12″
- TABLE SIZE: 84″ x 13″
- FENCE SIZE: 36″ x 5″
- MOTOR: 15 Amp.
- VOLTAGE: 220V, 1 phase, 60Hz
- ASSEMBLED DIMENSIONS (LXWXH) / WEIGHT: 84″ x 40″ x 43″ / 706 lbs
- PACKAGING DIMENSIONS (LXWXH) / WEIGHT: 88-7/8 x 29-1/2″ x 40-5/8″ / 920 lbs
