Description:
- All ball bearing die cast construction
- Conveyor belt tracking is easy to adjust
- Easy clamping sanding belt loading system
- 2-1/2″ dust chute
- A metric and imperial depth scale is provided for thickness adjustment
- Metal stand included
- Important: With its open ended design this machine can sand a 32″ wide piece in 2 passes
Specifications:
- DRUM MOTOR: 10 Amp.
- BELT FEED MOTOR: 1/8 HP
- MAXIMUM WIDTH OF SANDING: 2″ x 16″
- MAXIMUM SANDING CAPACITY PER PASS: 1/64″
- MAXIMUM THICKNESS OF BOARD: 5″
- MINIMUM THICKNESS OF BOARD: 1/8″
- MINIMUM LENGTH OF BOARD: 2-1/4″
- BELT: 3″ x 96″
- FEEDING SPEED: 0-31 SIPM
- NUMBER OF SANDING DRUMS: 1
