Description:
- 26″ width by 12″ thickness capacity
- Variable feed speed
- Heavy-duty base and steel frame provides stability during operation
- The parallelism between the sanding drums and the conveyor table is easily adjusted by turning adjustment screws
- Magnetic safety switch
- Twin 4″ dust chutes for dust collector hook-up
- Two 5″ aluminum sanding drums are precision balanced and driven by 2 V-belts
- A metric and imperial depth scale is provided for thickness adjustment
Specifications:
- SANDING DRUM MOTOR: 3 HP, 16 Amp, 220V
- CONVEYOR BELT MOTOR: 1/6HP , 220V, 1 phase
- MAXIMUM WIDTH OF SANDING: 26″
- MAXIMUM THICKNESS OF BOARD: 12″
- MINIMUM THICKNESS OF BOARD: 1/4″
- MINIMUM LENGTH OF BOARD: 5″
- ABRASIVE BELT: 5″ x 120″
- VARIABLE FEEDING SPEED: 3-20 SFPM
- NUMBER OF SANDING DRUMS: 2
- SANDING DRUM SPEED: 1,550 RPM
