Description:
- Powerful 15 Amp. heavy-duty motor with reset
- Large 21″ x 30″ cast aluminum table with extendable rails and table allowing up to 25″ rip capacity to the right of the blade
- Folding stand with large 8″ wheels for portability
- All in one height/bevel adjusting handwheel with blade height lock and micro bevel angle adjustment
- On-board storage secures rip fence, miter gauge, blade guard, anti-kickback fingers, extra blades, push stick and blade wrenches during transport
- Blade tilts 0° to 45° with detents for versatile angle cutting
- Table has writable surface insert to mark sides of blade for cut alignment
- 2-1/2″ dust port for connection to standard shop vacuum
- Extendable rails and table allowing up to 25” rip capacity
- Comes with 10″ x 40 teeth general purpose blade, rip fence, miter gauge, Standard and Dado table inserts, push stick and wrenches
- Double insulated
Specifications:
- BLADE DIAMETER: 10″
- DEPTH OF CUT AT 45°: 2-1/2″
- DEPTH OF CUT AT 90°: 3-1/2″
- TABLE SIZE: 30″ – 40″ x 21″
- DIAMETER OF ARBOR: 5/8″
- ARBOR SPEED: 4,400 RPM
- MOTOR: 15 Amp.
- VOLTAGE: 110V, 1 phase, 60Hz
- ASSEMBLED DIMENSIONS(LXWXH) / WEIGHT: 46-3/4″ x 26″ x 40″ / 70 lbs
- PACKAGING DIMENSIONS (LXWXH) / WEIGHT: 38-1/2″ x 28″ x 17″ / 75 lbs
