Description:
- Powerful 19 AMP 220 VOLT motor
- Solid cast-iron extension tables
- Mobile base system built into cabinet
- A spiral cutterhead is 50% quieter than a conventional cutterhead
- Table raises and lowers on four precision ground columns for extra stability
- Anti-kickback fingers in front of the infeed roller prevents wood kickback
- Magnetic safety switch
- Lever allows you to shift gears for changing feed rates for excellent results in planing hard and soft woods
- Knives rest on adjustable Jack Screws; lock bar and lock screws keep knives in place
- Comes with knife setting gauge and 5″ dust chute
Specifications:
- MAXIMUM PLANING WIDTH: 20″
- MAXIMUM PLANING THICKNESS: 8″
- MAXIMUM DEPTH OF CUT: 3/32″
- TOTAL SURFACE OF WORK TABLE: 56-1/2″ x 20″
- CUTTERHEAD SPEED: 5,000 RPM
- CUTTERHEAD DIAMETER: 3.15″
- NUMBER OF KNIVES: 92
- FEED RATE: 2 (16-20) FPM
- NUMBER OF CUTS PER INCH: 104-83
- MOTOR: 19 Amp.
