- Powerful 1.5 HP direct ball bearing drive motor
- Heavy-duty cast-iron tilting tables and frame
- Adjustable belt unit operates vertically, horizontally or at any set angle in between
- 2 – dust chutes (2” & 2-1/4”) for vacuum or dust collector hook-up
- Sturdy cabinet stand
- Quick belt release mechanism
- Comes complete with heavy-duty miter gauge and back stop
| MODEL | KC-780FX |
| Belt | 6” x 48” |
| Belt lift | 0° – 90° |
| Belt speed | 1,066 SFPM /pi/min |
| Disc | 12” |
| Disc speed | 1,725 RPM/tr/min |
| Motor | 10.5 Amp |
| Voltage | 120V, 1 phase, 60 Hz |
| Assembled dimensions (LxWxH)/weight | 36” x 17-1/2” x 54-1/2” / 165 lbs |
| Package dimensions (LxWxH)/weight | 32” x 30” x 21” / 178 lbs |
