Description:
- 1 HP high performance DC motor
- Reliable single board computer microprocessor for precise control
- Precise spindle speed digital readout
- Variable speed from 450 – 3,800 RPM
- 24 indexing positions with spindle lock
- Work light with 18″ flex. shaft for improved visibility during intricate work
- Heavy-duty precision cast iron bed ensures stability, accepts optional extension bed for turning operations up to 44″
- Comes complete with 3″ faceplate, 6″ and 12″ tool rests with 1″ post diameter, MT2 spur centre and MT2 heavy-duty live centre, safety goggles, knock-out rod, tool storage rack, screwdriver and 4 hex. keys
Specifications:
- SWING OVER BED: 12″
- DISTANCE BETWEEN CENTRES: 18″
- SPINDLE SIZE: 1″ x 8 TPI
- SPINDLE BORE: 3/8″
- SPINDLE SPEEDS: 2 (450-1,800 / 950-3,800 RPM)
- HEADSTOCK AND TAILSTOCK TAPER : MT 2
- DC MOTOR : 1 HP / 7 Amp.
- VOLTAGE: 110V, 1 phase, 60 Hz
- ASSEMBLED DIMENSIONS (LXWXH) / WEIGHT: 39″ x 15″ x 18″ / 105 lbs
- PACKAGING DIMENSIONS (LXWXH) / WEIGHT: 36″ x 14-1/2″ x 18-3/8″ / 110 lbs
