Features & Benefits:
- High Performance Magnesium Blade Case And Base
- Cutting Depth Capacity Of 2-1/2″ (63.5 Mm), Electric Brake
- Electric Brake for operator safety
- Dual LED Job Lights illuminate cut line
- Blower feature keeps cutting line free of sawdust
- Bevel Capacity of 56o with Positive Stops at 22.5°, 45°, and 56°
- Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Specifications:
- Blade Diameter –7-1/4″ (185 mm)
- Arbor –5/8″ (15.88 mm)
- Maximum Cutting Capacities:
- 0° –2-1/2″ (63.5 mm)
- 45° –1-3/4″ (45 mm)
- 56° –1-3/8″ (35 mm)
- No Load Speed –5,800 RPM
- AMPS (120V) –15.0 A
- Vibration Level –(Unavailable)
- Noise Level –(Unavailable)
- Overall Length –12-1/2″ (317 mm)
- Net Weight –10.6 lbs (4.8 kg)
Standard Equipment:
7-1/4″ C.T. Blade 24T (1 Ea. A-94530-10), Hex Wrench 6 (783204-6), Guide Rule (164095-8), Plastic Carrying Case (158279-8)
