Features & Benefits:
- High Performance Magnesium Blade Case And Base
- Cutting Depth Capacity Of 3″ (75.5 mm)
- Electric Brake for operator safety
- Dual LED Job Lights illuminate cut line
- Blower feature keeps cutting line free of sawdust
- Bevel Capacity of 50o with Positive Stops at 22.5°, 45°, and 50°
- Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Specifications:
- Blade Diameter –8-1/4″ (210 mm)
- Arbor –5/8″ (15.88 mm)
- Maximum Cutting Capacities:
- 0° — 3″ (75.5 mm)
- 45° — 2-1/4″ (57 mm)
- 50° — 2″ (51.5 mm)
- No Load Speed –5,200 RPM
- AMPS (120V) –15.0 A
- Vibration Level –3.0 m/s2
- Noise Level –95 dB(A)
- Overall Length –13-1/8″ (332 mm)
- Net Weight –11.2 lbs (5.1 kg)
Standard Equipment:
8-1/4″ C.T. Blade 24T (D-21521), Hex Wrench 6 (783204-6), Guide Rule (164095-8)
