Features & Benefits:
- Hypoid Gear System Provides Increased Power Transmission
- Cutting Capacity Of 2-3/8″ (60 mm)
- Ideal for Framers, Home Builders, Masons, and Contractors
- High quality, Hardened Steel Hypoid Gears do not wear like bronze-alloy worm drive gears
- Bevel Capacity of 51.5° with Positive Stops at 45o and 51.5o ideal for cutting trusses and rafters
- Ergonomic Soft Rubber Rear Grip design for vibration absorption and comfortable operation
Specifications:
- Blade Diameter –7-1/4″ (185 mm)
- Arbor –5/8″ (15.88 mm)
- Maximum Cutting Capacities:
- 0° –2-3/8″ (60 mm)
- 45° –1-3/4″ (44 mm)
- 50° –1-9/16″ (40 mm)
- No Load Speed –4,500 RPM
- AMPS (120V) –15.0 A
- Vibration Level –(Unavailable)
- Noise Level –(Unavailable)
- Overall Length –17-3/8″ (442 mm)
- Net Weight –14.3 lbs (6.5 kg)
Standard Equipment:
7-1/4″ Blade 24T , Hex Wrench 6 (783204-6)
