Features & Benefits:
- Perfect For Timber Framing And Log Home Building
- Cuts lap joints up to 5-1/8″
- Notches or cuts holes in thick wood stock quickly, cleanly and accurately
- Quick horizontal chain lever for widening holes
- Base mounts onto a max. 12″ beam
- Large adjustable vise for attaching firmly onto logs
Specifications:
- Capacities:
- Max Hole Width (Longitudinal) –5-1/8″ (130 mm)
- Max Hole Width (Transverse) –1-1/4″ (31.5 mm)
- Max Hole Depth –6-1/8″ (155 mm)
- No Load Speed –3,200 RPM
- AMPS (120V) –10.5 A
- Vibration Level — 2.5 m/s2
- Noise Level — 90 dB(A)
- Dimensions — 20-1/8″ x 11-3/4″ x 20-1/4″ (512 mm x 298 mm x 513 mm)
- Net Weight — 38.1 lbs (17.3 kg)
Standard Equipment:
5/8 Cutting Chain (A-16570), Chain Bar Assy (133571-3), Wrench 13-17 (781204-0), Oil Supply (182229-1)
