Features & Benefits:
- SDS-MAX Shank
- Hammer & Rotation / Hammer Only
- Variable Speed, Constant Speed Control, Soft Start
- Anti-Vibration Technology (AVTTM) actively counteracts vibration of tool for greatly reduced transmission to operator
- Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
- Constant Speed Control maintains constant speed under heavy load
- Soft Start feature gradually increases speed to eliminate start up shock
- Variable Speed Dial allows operator to adjust speed based on materials or application
- 16 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
- One-Touch Sliding Chuck for easy bit installation and removal
- LED Service Light indicates appropriate time to change carbon brushes
- LED Power Light indicates active power supply
- Vibration Absorbing Handle with Ergonomic Soft Rubber Grip for vibration absorption and comfortable operation
- Includes Straight (Drilling) and D-Style (Demolition) Side Handles
Specifications:
- Bit Type — SDS-MAX
- Maximum Capacities:
- Concrete (TCT) — 1-3/4″ (45 mm)
- Concrete (Core Bit) — 5″ (125 mm)
- No Load Speed — 130 – 280 RPM
- Blows Per Minute — 1,250 – 2,750 BPM
- Impact Energy — 12.5 J (9.2 ft. lbs)
- AMPS (120V) — 13.5 A
- Vibration Level — 7.5 m/s2 (Drilling) / 7.0 m/s2 (Chiseling)
- Noise Level — 94 dB(A)
- Overall Length — 18″ (458 mm)
- Net Weight — 19.8 lbs (9.0 kg)
Standard Equipment:
Bit Grease (194683-7), Straight Side Handle Incl. Depth Gauge (135209-6), D-Style Side Handle (134890-0), Cleaning Cloth (443122-7), Plastic Carrying Case (196188-3)
