Features & Benefits:
- Highest Impact Energy Rating (21 J) In Class!! SDS-MAX Shank
- Hammer & Rotation / Hammer Only
- Variable Speed, Constant Speed Control, Soft Start, Soft No-Load
- Low noise and vibration level for maximum operator comfort and safety
- Advanced Anti-Vibration Technology (AVTTM) system incorporates vibration absorbing housing, active dynamic vibration absorber and damper spring to actively counteract the vibration of the tool for greatly reduced transmission to the operator
- Incorporates both trigger and locking switches for ease of operation in intermittent drilling and prolonged demolition applications
- Torque limiter stops bit if bit jams for increased operator safety and tool protection
- Soft start feature gradually increases speed to eliminate start up shock
- No load motor suppression limits vibration and bit deflection when idling
- Variable speed dial allows operator to adjust speed based on materials or application
- 24 angle bit positions enable chisels to be positioned at the optimum angle of operation
- One-touch sliding chuck for easy bit installation and removal
- LED service light indicates appropriate time to change carbon brushes
- LED power light indicates active power supply
- Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Specifications:
- Bit Type — SDS-MAX
- Maximum Capacities:
- Concrete (TCT) — 2-1/16″ (52 mm)
- Concrete (Core Bit) — 6-5/16″ (160 mm)
- No Load Speed — 150 – 310 RPM
- Blows Per Minute –1,100 – 2,250 BPM
- Impact Energy — 21 J (15.5 ft.lbs)
- AMPS (120V) — 15.0 A
- Vibration Level — 9.0 m/s2
- Noise Level — 98 dB(A)
- Overall Length — 23-1/2″ (599 mm)
- Net Weight — 26.2 lbs (11.9 kg)
Standard Equipment:
Bit Grease (194683-7), D-Style Side Handle (135283-4), Straight Side Handle (135629-4), Cleaning Cloth (443122-7), Depth Gauge (331955-1), Plastic Carrying Case (142296-8)
