Features & Benefits:
- Clean, Precise Work In Keystone Plate, Deck Plate And Other Corrugated Sheet Materials
- Die rotates 360o with positive stops at 0o, 90o Left, 90o Right and 180o for simple and accurate adjustment on the jobsite
- Large 1/4″ stroke
- Built-in thickness gauge for operator convenience
- Easy punch and die replacement for less down time
- Sliding lock-on switch for operator convenience
- Ergonomic slim body design for easy gripping
Specifications:
- Maximum Capacities:
- Mild Steel –1.6 mm / 16 ga
- Stainless –1.2 mm / 18 ga
- Aluminum –2.5 mm / 13 ga
- AMPS (120V) — 5.0 A
- Vibration Level — 7.0 m/s2
- Noise Level –83 dB(A)
- Strokes Per Minute –2,200 SPM
- Minimum Cutting Radius:
- Outside Edge –2″ (50 mm)
- Inside Edge –1-3/4″ (45 mm)
- Overall Length –10-1/4″ (261 mm)
- Net Weight –3.5 lbs (1.6 kg)
Standard Equipment:
Wrench 32 (781028-4), Hex Wrench 2.5 (783208-8), Die (A-15051), Punch(A-83951)
