Features & Benefits:
- Trigger Switch with Lock-On and Lock-Off Features
- Electronic Speed Control, Electric Brake, Variable Speed
- Electronic Speed Control maintains constant speed under heavy load
- Linear Bearing Slide Mechanism allows extremely smooth plunge action
- Larger Ball Bearings on Armature enhance durability of tool
- Labyrinth Retainers and Fan prevent contamination of motor
- Plunge Depth can be adjusted from the bottom of the router when mounted in a router table
- Trigger Switch with Lock-On/Off Button located on handle for operator convenience
- 3 Stage Depth Adjustments ideal for use when performing deep or repetitive cutting operations
- Four Raised Ribs on top of Motor Housing provide a stable platform during bit changes
- Dual LED Job Lights with Afterglow
- Sub-Base accepts industry standard template guides
- Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
- Can be used with 55″ (194368-5) or 118″ (194367-7) Guide Rails and Router Guide Rail Adapter (194579-2) for precision routing applications
Specifications:
- Collet Capacity –1/2″ (12.7 mm)
- Plunge Capacity –2-3/4″ (70 mm)
- No Load Speed –9,000 – 22,000 RPM
- AMPS (120V) –15.0 A
- Vibration Level –4.5 m/s2
- Noise Level –87 dB(A)
- Base Diameter –6-11/16″ (170 mm)
- Overall Height –12-1/4″ (312 mm)
- Net Weight –13.4 lbs (6.1 kg)
Standard Equipment:
Depth Adjustment Knob (158980-5), 1/4″ Collet Sleeve (763803-0), 1/2″ Collet Cone (763622-4), Wrench 24 (781030-7)
