High Bay Extender Module, Passive Infrared, 120/230/347VAC, 360-deg Field of View.FEATURES:* Sensor – Low Voltage, Passive Infrared* Type – High Bay Occupancy Sensor* Voltage – 120/230/347 VAC* Field of View – deg – 360-deg* Coverage – area – 15-40 sq-ft * Beam Pattern – 100-feet Diameter At 40-ft Height* Color – White* Mount – Surface* Operating Temperature: 32-158 deg F. * Humidity: 20-90 Percent
Compact line voltage sensor with integral lens for all high bay applications
360° coverage from 15’-40’; lens covers 100’ diameter area from 40’ height; rotatable snap-on aisleway masking
Adjustable time delay and hold-off daylighting level
HBP-111 adjustable via handheld wireless configuration tool
120, 277, 347V, 60Hz or 230V, single phase, 50Hz operation
cULus listed snap-in mounting hardware
Compact line voltage sensor with integral lens for all high bay applications
360° coverage from 15’-40’
Specifications
Brand Name
WattStopper
Sub Brand
Pass & Seymour
Item Name
High/Low-Bay Extender Module
Material
Plastic
Type
High Bay Occupancy Sensor
Voltage Rating
24 VDC
Color/Finish
White
Application
For Warehouses, Industrial Floor Parking Lots
UPC
754182935093
Packages
